Default content placeholders in a SharePoint master page

If you’ve spent much time in SharePoint Designer 2007, you know what content placeholders are, and you know that you need to understand them before you start modifying master pages on a SharePoint site.



For those of you who haven’t worked with content placeholders, here’s an overview…



A content placeholder is a piece of code (starts with <asp:ContentPlaceHolder… >) that exists on a master page. It works together with a piece of code called a content region (starts with <asp:Content… >) that exists on a content page. Content placeholders are used to designate parts of the master page that will display replaceable content, the content that originates from a content page. This is how master pages are able to serve as templates for other pages on your web site.



You establish the general look and feel of your site in a master page—the colors, logos, global navigation, header and footer information. Once you establish the look and feel on a master page, you designate parts of the page that will display unique content originating from a content page, such as corporate documents, company or team events, and business forms. As a SharePoint site, you also need to consider SharePoint collaboration features, like lists, libraries, and wikis. To integrate a master page with your content pages, you use content placeholders.





To see the content placeholders that are being used on your SharePoint site, open your site’s default master page in SharePoint Designer.



If you want to change the value of a content placeholder for your entire site, make the change to the default master page. If you want to change the content inside of a placeholder for a content page on your site, make the change to the content page.





When you open a master page in SharePoint Designer, you see this:





(Tip: You may need to turn on the Empty Containers and Visible Borders visual aids in Designer to view the master page this way.)



To view the default content placeholders, open the Master Page toolbar. You do this by clicking View > Toolbars > Master Page. A floating toolbar appears. Click the down arrow and then choose one of the content placeholders (see figure).





This highlights the content placeholder on the master page, which in this case is the PlaceHolderTitleBreadcrumbcontent control.







On a Windows SharePoint Services 3.0 master page (Default.master), there are 30 default content placeholders.



I’ve listed them below, along with a preview of what each content placeholder looks like on your final web pages. The preview is, in effect, a combination of the content placeholder from the master page and the contents of the corresponding content region from the content page. I’ve highlighted the content placeholder with a red outline to make it easier to see.



There are a few content placeholders that have no visual representation. For example, the PlaceHolderBodyAreaClass content placeholder serves as a placeholder for styles. I placed these content placeholders at the end, about where they appear on the master page.



PlaceHolderGlobalNavigationSiteMap
Site map used by the global navigation breadcrumb



PlaceHolderGlobalNavigation
Global navigation breadcrumb



PlaceHolderSiteName
Site name



PlaceHolderSearchArea
Search box area





PlaceHolderTopNavBar
Top navigation area



PlaceHolderHorizontalNav
Top navigation menu for the page (defaults with the Home tab)



PlaceHolderPageImage
Page icon in the upper-left area of the page



PlaceHolderCalendarNavigator
Date-picker for navigating a calendar, when enabled



PlaceHolderTitleAreaSeparator
Displays shadows for the title area



PlaceHolderLeftNavBarDataSource
Data source for the left navigation menu



PlaceHolderLeftNavBarTop
Top of the left navigation area





PlaceHolderLeftNavBar
Left navigation area (contains the Quick Launch)



PlaceHolderLeftNavBarBorder
Border element on the left navigation bar



PlaceHolderLeftActions
Bottom of the left navigation area



PlaceHolderPageTitleInTitleArea
Page title shown immediately below the breadcrumbs



PlaceHolderPageDescription
Description of the page contents



PlaceHolderTitleBreadcrumb
Main content breadcrumb area



PlaceHolderTitleLeftBorder
Left border of the title area



PlaceHolderTitleRightMargin
Right margin of the title area



PlaceHolderBodyLeftBorder
Border element for the main page body



PlaceHolderMain
Main content of the page



PlaceHolderBodyRightMargin
Right margin of the main page body



PlaceHolderMiniConsole
A place to show page-level commands (for example, the Edit Page, History, and Incoming Links WIKI commands)



WSSDesignConsole
The page editing controls when the page is in Edit Page mode



PlaceHolderNavSpacer
The width of the left navigation area



PlaceHolderFormDigest
The “form digest” security control



PlaceHolderUtilityContent
Extra content at the bottom of the page



SPNavigation
Used for additional page editing controls. (Empty by default in Windows SharePoint Services 3.0.)



PlaceHolderBodyAreaClass
Additional body styles in the page header



PlaceHolderTitleAreaClass
Additional styles in the page header
